Features

• Mobile cable control unit
• Bi-directional rotation
• Self centering universal wheel chuck
• Rim pliers and rim lever standard

Standard Accessories

• Rim Lever
• Bead Lifting Lever
• Rim Pliers

Optional Accessories

• Tubeless Roller
• Jaw Protections for Alloy Rims (Set of 4)
• Pliers for Alloy Rims
• Bead Lifting Guide Lever for Agricultural Tires
• Set of Screw Clamps for Contemporaneous Bead Breaking of Rim Ring

Specifications

• Power Supply: 220VAC, 50/60 Hz, 1 ph
• Rim Clamping Range: 13″ – 27″
• Max. Tire Outside: 1,600 mm (63″)
• Max. Tire Width: 780 mm (30″)
• Max. Tire Weight: 3,300 lbs (1,500 Kg)
• Bead Breaker Force: 4,100 lbs (1,860 Kg)
• Operating Pressure: 130 bar (1,885 psi)
• Gross Ship. Weight: 1,415 lbs (640 Kg)
